Case Studies
The recorded substrate-preparation stage for the carbon-steel kiln shell before the coating system was applied.
Heat loss from the cement kiln and the need to improve heat utilization.
Prepare the carbon-steel shell to Sa 2, apply the specified high-temperature anti-corrosion primer by spray, then build the thermal-insulation layer with four brush-applied coats.
ZM99-01A05 high-temperature anti-corrosion coating + ZM99-01A18 high-temperature thermal insulation coating
Surface preparation to Sa 2; spray-applied primer followed by four brush-applied insulation coats.
The coating reached the design thickness, was uniform and consistent in colour, showed no wrinkling or agglomeration, and passed the recorded construction acceptance.
The recorded construction acceptance confirmed the specified coating build and a uniform, defect-free finish.
